3 generation house

Contemplating care between generations, a family comprising of two households decides to build a house together. While the younger couple already lives in the city, the grandparents live in the countryside and are keen to move back to the proximity of urban amenities.

three generation house by BETA concept scheme growth over time

Adapting with time

For this mini-apartment building a concept was devised capable of accommodating changing spatial demands over time. The elderly couple occupies the top apartment with generous views across the cityscape. This apartment has an elevator and level floors, making it very suitable for the elderly. The bottom apartment has an office and a direct relationship with the garden, making it ideal for a working family with young children.

Instead of reducing vertical circulation to a necessity, it occupies the heart of the building. Omnipresent as a sculptural element in the lower apartment, the system gradually transforms into a series of voids higher up in the building. This central access system allows a ‘surplus floor’ to be combined with either apartment. Initially used as a space for guests for the topmost apartment, this space can be easily added to the lower apartment through a few elementary technical amendments.

three generation house by BETA photo interior kitchen void and balconies by Ossip

three generation house by BETA photo interior kitchen with yellow staircase by Ossip

three generation house by BETA photo interior roof terrace with awnings by Ossip

Open vs. enclosed

As though a clair-obscur, the gradient in the building’s plan is emphasized in the building’s contrasting façades. The Northern façade is mostly closed to reduce thermal loss and reduce sound exposure along the busy street. Towards the South the building opens up completely, maximizing passive solar gain and the connection with the outdoors. In between the two contrary façades, the building’s plan undergoes a gradual transformation, from compartmentalized in the North, to open-plan and structured with free-form elements towards the South. Here the building is concluded with an informal filter-like balcony layer.

Material and composition

In a near elementary detailing, the building communicates its composition and materials communicate their purpose. Hence the Southern façade is clad only with minimal triple glazing window frames to underline the building’s relationship with the outdoors. The remaining structural walls are composed of large format concrete masonry, wrapped in high-grade thermal insulation. Between these walls, bare concrete slabs span 8 meters and offer a clear plane on which warmer timber elements define spatial moments. Closed and bare towards the North, light and fragile towards the South, the building is a composition of contrasts.

three generation house by BETA daytime photo north grid facade by Ossip

three generation house by BETA daytime photo south facade with balconies by Ossip

three generation house by BETA construction detail north façade with concrete masonry

three generation house by BETA construction detail south façade concrete floor slabs and steel balcony

three generation house by BETA photo construction site concrete masonry grid facade

three generation house by BETA photo construction site with recessed sliding door detail

three generation house by BETA photo interior with mahogany closets in loft space by Ossip

three generation house by BETA photo interior bathroom balcony by Ossip

three generation house by BETA photo interior staircase with steel railings by Ossip

three generation house by BETA plan ground floor drawing

three generation house by BETA plan first floor drawing

three generation house by BETA plan second floor drawing

three generation house by BETA plan third floor drawing

three generation house by BETA plan fourth floor drawing

three generation house by BETA longitudinal section drawing

three generation house by BETA photo interior bedroom with balcony by Ossip

three generation house by BETA photo interior detail steel railing and yellow wall by Ossip

three generation house by BETA photo interior window detail with concrete lintel masonry by Ossip

Project Details

YEAR

2016 – 2018

CLIENT

private

SITE

Buiksloterham, Amsterdam

STATUS

built

COLLABORATORS

Huibert Spoorenberg (climate advisor), Huibers Constructieadvies (engineer), ATB Leerbroek (contractor)

TEAM

Auguste van Oppen, Evert Klinkenberg

PHOTOGRAPHY

Ossip van Duivenbode
